Oberton 8M150

Mid-range

8″ / 203 mm
Nominal diameter
68 Hz
Resonance
0.22
Q factor
96 dB
Sensitivity
± 3.25 mm
Linear excursion
300 W
Program Power
Driver
Port
Combined
Frequency response
Hz
Impedance
Ω
Impedance Phase
°
Excursion
mm
Velocity
m/s
SPL
dB
Acoustical Phase
°
Group Delay
ms
Transient response
ms
Discard
Apply
Sensitivity (1W, 1m, infinite baffle)
SPL1W
96.2
dB
Frequency response
80 - 5000
Hz

Thiele & Small parameters

Resonance frequency (free air)
fS
68.2
Hz
Mechanical quality factor
QMS
6.07
Electrical quality factor
QES
0.23
Total quality factor
QTS
0.22

Large signal parameters

Maximum linear excursion
xmax
3.25
mm
Air volume displaced at xmax
VD
66
cm³
Power handling
P
150
W
Program power
Pmax
300
W

Voice Coil

Nominal impedance
Z
8
Ω
DC resistance
RE
5.1
Ω
Inductance (1kHz)
LE
0.74
mH
VC Diameter
51
mm
Winding height
HVC
10
mm
Winding material
Aluminium
Former material
Kapton

Magnet

Flux density
B
1.35
T
Force factor
Bl
11.62
N/A
Motor constant
Bl/√RE
5.17
N/√W
Air gap height
HAG
7
mm
Material
Ferrite

Diaphragm

Effective diameter
160
mm
Effective area
SD
202
cm²
Moving mass
MMS
14.1
g
Moving mass (without air load)
MMD
11.8
g
Material
Paper

Suspensions

Stiffness
KMS
2.58
N/mm
Compliance
CMS
387
µm/N
Equivalent volume to the compliance
VAS
21.6
L
Mechanical resistance
RMS
0.99
N·s/m

Dimensions

Nominal diameter
8
203
mm
Overall diameter
225
mm
Baffle cutout diameter
187
mm
Overall depth
90
mm
Volume occupied by the driver (estimated)
1.1
L
Net weight
3.25
kg
Frame material
Die cast aluminium
Oberton 8M150 SPL
Oberton 8M150 Dimensions
