15″ / 380 mm
Nominal diameter
26 Hz
Resonance
0.32
Q factor
90 dB
Sensitivity
± 20.65 mm
Linear excursion
2000 W
Program Power
.jpg)
.jpg)
.jpg)
Sensitivity (1w, 1m, infinite baffle)
SPL1W
89.8
dB
Frequency response
18 - 500
Hz
Thiele & Small parameters
Resonance frequency (free air)
fS
26.0
Hz
Mechanical quality factor
QMS
13.47
Electrical quality factor
QES
0.33
Total quality factor
QTS
0.32
Large signal parameters
Maximum linear excursion
xmax
20.65
mm
Air volume displaced at xmax
VD
1745
cm³
Power handling
P
1000
W
Program power
Pmax
2000
W
Voice Coil
Nominal impedance
Z
2 x 2
Ω
DC resistance (in series)
RE
4.2
Ω
Inductance (1kHz, in series)
LE
5.92
mH
Magnet
Force factor (in series)
Bl
26.53
N/A
Motor constant
Bl/√RE
12.9
N/√W
Diaphragm
Effective diameter
328
mm
Effective area
SD
845
cm²
Moving mass
MMS
335
g
Moving mass (without air load)
MMD
318.1
g
Suspensions
Stiffness
KMS
8.94
N/mm
Compliance
CMS
112
µm/N
Equivalent volume to the compliance
VAS
113
L
Mechanical resistance
RMS
4.064
N·s/m
Dimensions
Nominal diameter
15
″
380
mm
Baffle cutout diameter
350
mm
Mounting depth
215
mm
Volume occupied by the driver (estimated)
4.3
L
